#include <kronecker.h>

Collaboration diagram for TKronMtx:

Public Member Functions
	TKronMtx ()
	TKronMtx (const int &Dim)
	TKronMtx (const TFltV &SeedMatrix)
	TKronMtx (const TKronMtx &Kronecker)
void	SaveTxt (const TStr &OutFNm) const
TKronMtx &	operator= (const TKronMtx &Kronecker)
bool	operator== (const TKronMtx &Kronecker) const
int	GetPrimHashCd () const
int	GetSecHashCd () const
int	GetDim () const
int	Len () const
bool	Empty () const
bool	IsProbMtx () const
TFltV &	GetMtx ()
const TFltV &	GetMtx () const
void	SetMtx (const TFltV &ParamV)
void	SetRndMtx (const int &MtxDim, const double &MinProb=0.0)
void	PutAllMtx (const double &Val)
void	GenMtx (const int &Dim)
void	SetEpsMtx (const double &Eps1, const double &Eps0, const int &Eps1Val=1, const int &Eps0Val=0)
void	SetForEdges (const int &Nodes, const int &Edges)
void	AddRndNoise (const double &SDev)
TStr	GetMtxStr () const
const double &	At (const int &Row, const int &Col) const
double &	At (const int &Row, const int &Col)
const double &	At (const int &ValN) const
double &	At (const int &ValN)
int	GetNodes (const int &NIter) const
int	GetEdges (const int &NIter) const
int	GetKronIter (const int &Nodes) const
int	GetNZeroK (const PNGraph &Graph) const
double	GetEZero (const int &Edges, const int &KronIter) const
double	GetMtxSum () const
double	GetRowSum (const int &RowId) const
double	GetColSum (const int &ColId) const
void	ToOneMinusMtx ()
void	GetLLMtx (TKronMtx &LLMtx)
void	GetProbMtx (TKronMtx &ProbMtx)
void	Swap (TKronMtx &KronMtx)
double	GetEdgeProb (int NId1, int NId2, const int &NKronIters) const
double	GetNoEdgeProb (int NId1, int NId2, const int &NKronIters) const
double	GetEdgeLL (int NId1, int NId2, const int &NKronIters) const
double	GetNoEdgeLL (int NId1, int NId2, const int &NKronIters) const
double	GetApxNoEdgeLL (int NId1, int NId2, const int &NKronIters) const
bool	IsEdgePlace (int NId1, int NId2, const int &NKronIters, const double &ProbTresh) const
double	GetEdgeDLL (const int &ParamId, int NId1, int NId2, const int &NKronIters) const
double	GetNoEdgeDLL (const int &ParamId, int NId1, int NId2, const int &NKronIters) const
double	GetApxNoEdgeDLL (const int &ParamId, int NId1, int NId2, const int &NKronIters) const
double	GetEdgeProb (const uint &NId1Sig, const uint &NId2Sig, const int &NIter) const
PNGraph	GenThreshGraph (const double &Thresh) const
PNGraph	GenRndGraph (const double &RndFact=1.0) const
void	Dump (const TStr &MtxNm=TStr(), const bool &Sort=false) const
Static Public Member Functions
static uint	GetNodeSig (const double &OneProb=0.5)
static int	GetKronIter (const int &GNodes, const int &SeedMtxSz)
static PNGraph	GenKronecker (const TKronMtx &SeedMtx, const int &NIter, const bool &IsDir, const int &Seed=0)
static PNGraph	GenFastKronecker (const TKronMtx &SeedMtx, const int &NIter, const bool &IsDir, const int &Seed=0)
static PNGraph	GenFastKronecker (const TKronMtx &SeedMtx, const int &NIter, const int &Edges, const bool &IsDir, const int &Seed=0)
static PNGraph	GenDetKronecker (const TKronMtx &SeedMtx, const int &NIter, const bool &IsDir)
static void	PlotCmpGraphs (const TKronMtx &SeedMtx, const PNGraph &Graph, const TStr &OutFNm, const TStr &Desc)
static void	PlotCmpGraphs (const TKronMtx &SeedMtx1, const TKronMtx &SeedMtx2, const PNGraph &Graph, const TStr &OutFNm, const TStr &Desc)
static void	PlotCmpGraphs (const TVec< TKronMtx > &SeedMtxV, const PNGraph &Graph, const TStr &FNmPref, const TStr &Desc)
static void	KronMul (const TKronMtx &LeftPt, const TKronMtx &RightPt, TKronMtx &OutMtx)
static void	KronSum (const TKronMtx &LeftPt, const TKronMtx &RightPt, TKronMtx &OutMtx)
static void	KronPwr (const TKronMtx &KronPt, const int &NIter, TKronMtx &OutMtx)
static double	GetAvgAbsErr (const TKronMtx &Kron1, const TKronMtx &Kron2)
static double	GetAvgFroErr (const TKronMtx &Kron1, const TKronMtx &Kron2)
static TKronMtx	GetMtx (TStr MatlabMtxStr)
static TKronMtx	GetRndMtx (const int &Dim, const double &MinProb)
static TKronMtx	GetInitMtx (const int &Dim, const int &Nodes, const int &Edges)
static TKronMtx	GetInitMtx (const TStr &MtxStr, const int &Dim, const int &Nodes, const int &Edges)
static TKronMtx	GetMtxFromNm (const TStr &MtxNm)
static TKronMtx	LoadTxt (const TStr &MtxFNm)
static void	PutRndSeed (const int &Seed)
Static Public Attributes
static const double	NInf = -DBL_MAX
static TRnd	Rnd = TRnd(0)
Private Attributes
TInt	MtxDim
TFltV	SeedMtx

Detailed Description

Definition at line 11 of file kronecker.h.

Constructor & Destructor Documentation

TKronMtx::TKronMtx ( ) [inline]

Definition at line 19 of file kronecker.h.

Referenced by GetMtxFromNm().

: MtxDim(-1), SeedMtx() { }

Here is the caller graph for this function:

TKronMtx::TKronMtx ( const int & Dim ) [inline]

Definition at line 20 of file kronecker.h.

: MtxDim(Dim), SeedMtx(Dim*Dim) { }

TKronMtx::TKronMtx ( const TFltV & SeedMatrix )

Definition at line 9 of file kronecker.cpp.

References IAssert, TVec< TVal >::Len(), MtxDim, and SeedMtx.

                                          : SeedMtx(SeedMatrix) {
  MtxDim = (int) sqrt((double)SeedMatrix.Len());
  IAssert(MtxDim*MtxDim == SeedMtx.Len());
}

Here is the call graph for this function:

TKronMtx::TKronMtx ( const TKronMtx & Kronecker ) [inline]

Definition at line 22 of file kronecker.h.

: MtxDim(Kronecker.MtxDim), SeedMtx(Kronecker.SeedMtx) { }

Member Function Documentation

void TKronMtx::AddRndNoise ( const double & SDev )

Definition at line 69 of file kronecker.cpp.

References At(), Dump(), TRnd::GetNrmDev(), Len(), and Rnd.

Referenced by GetInitMtx().

                                             {
  Dump("before");
  double NewVal;
  int c =0;
  for (int i = 0; i < Len(); i++) {
    for(c = 0; ((NewVal = At(i)*Rnd.GetNrmDev(1, SDev, 0.8, 1.2)) < 0.01 || NewVal>0.99) && c <1000; c++) { }
    if (c < 999) { At(i) = NewVal; } else { printf("XXXXX\n"); }
  }
  Dump("after");
}

Here is the call graph for this function:

Here is the caller graph for this function:

const double& TKronMtx::At	(	const int &	Row,
		const int &	Col
	)		const `[inline]`

Definition at line 46 of file kronecker.h.

References MtxDim, and SeedMtx.

Referenced by AddRndNoise(), GenFastKronecker(), GenRndGraph(), GenThreshGraph(), TKroneckerLL::GetApxEmptyGraphDLL(), TKroneckerLL::GetApxEmptyGraphLL(), GetApxNoEdgeDLL(), GetColSum(), GetEdgeDLL(), GetEdgeLL(), GetEdgeProb(), GetInitMtx(), GetLLMtx(), GetMtx(), GetMtxStr(), GetMtxSum(), GetNoEdgeDLL(), GetProbMtx(), GetRowSum(), TKroneckerLL::GradDescent(), TKroneckerLL::GradDescent2(), TKroneckerLL::GradDescentConvergence(), IsEdgePlace(), IsProbMtx(), KronMul(), KronSum(), LoadTxt(), TKronMaxLL::RoundTheta(), TKroneckerLL::RunMStep(), SaveTxt(), TKroneckerLL::SetBestDegPerm(), SetEpsMtx(), SetForEdges(), TKroneckerLL::SetRandomEdges(), TKroneckerLL::TestKronDescent(), and ToOneMinusMtx().

{ return SeedMtx[MtxDim*Row+Col].Val; }

Here is the caller graph for this function:

double& TKronMtx::At	(	const int &	Row,
		const int &	Col
	)		`[inline]`

Definition at line 47 of file kronecker.h.

References MtxDim, and SeedMtx.

{ return SeedMtx[MtxDim*Row+Col].Val; }

const double& TKronMtx::At ( const int & ValN ) const [inline]

Definition at line 48 of file kronecker.h.

References SeedMtx.

{ return SeedMtx[ValN].Val; }

double& TKronMtx::At ( const int & ValN ) [inline]

Definition at line 49 of file kronecker.h.

References SeedMtx.

{ return SeedMtx[ValN].Val; }

void TKronMtx::Dump	(	const TStr &	MtxNm = `TStr()`,
		const bool &	Sort = `false`
	)		const

Definition at line 636 of file kronecker.cpp.

References TStr::CStr(), TStr::Empty(), GetDim(), TVec< TVal >::Len(), SeedMtx, TVec< TVal >::Sort(), and ValV.

Referenced by AddRndNoise(), TKroneckerLL::GradDescent(), TKroneckerLL::GradDescent2(), TKroneckerLL::GradDescentConvergence(), TKroneckerLL::RunMStep(), TKroneckerLL::TestBicCriterion(), TKroneckerLL::TestKronDescent(), and TKroneckerLL::TestSamplePerm().

                                                             {
  /*printf("%s: %d x %d\n", MtxNm.Empty()?"Mtx":MtxNm.CStr(), GetDim(), GetDim());
  for (int r = 0; r < GetDim(); r++) {
    for (int c = 0; c < GetDim(); c++) { printf("  %8.2g", At(r, c)); }
    printf("\n");
  }*/
  if (! MtxNm.Empty()) printf("%s\n", MtxNm.CStr());
  double Sum=0.0;
  TFltV ValV = SeedMtx;
  if (Sort) { ValV.Sort(false); }
  for (int i = 0; i < ValV.Len(); i++) {
    printf("  %10.4g", ValV[i]());
    Sum += ValV[i];
    if ((i+1) % GetDim() == 0) { printf("\n"); }
  }
  printf(" (sum:%.4f)\n", Sum);
}

Here is the call graph for this function:

Here is the caller graph for this function:

bool TKronMtx::Empty ( ) const [inline]

Definition at line 32 of file kronecker.h.

References TVec< TVal >::Empty(), and SeedMtx.

Referenced by TKroneckerLL::GradDescentConvergence(), and TKroneckerLL::TestSamplePerm().

{ return SeedMtx.Empty(); }

Here is the call graph for this function:

Here is the caller graph for this function:

PNGraph TKronMtx::GenDetKronecker	(	const TKronMtx &	SeedMtx,
		const int &	NIter,
		const bool &	IsDir
	)		`[static]`

Definition at line 458 of file kronecker.cpp.

References TNGraph::AddEdge(), TNGraph::AddNode(), GetNodes(), TRnd::GetUniDev(), IsEdgePlace(), New(), Rnd, and SeedMtx.

                                                                                              {
  const TKronMtx& SeedGraph = SeedMtx;
  const int NNodes = SeedGraph.GetNodes(NIter);
  printf("  Deterministic Kronecker: %d nodes, %s...\n", NNodes, IsDir ? "Directed":"UnDirected");
  PNGraph Graph = TNGraph::New(NNodes, -1);
  TExeTm ExeTm;
  int edges = 0;
  for (int node1 = 0; node1 < NNodes; node1++) { Graph->AddNode(node1); }

  for (int node1 = 0; node1 < NNodes; node1++) {
    for (int node2 = 0; node2 < NNodes; node2++) {
      if (SeedGraph.IsEdgePlace(node1, node2, NIter, Rnd.GetUniDev())) {
        Graph->AddEdge(node1, node2);
        edges++;
      }
    }
    if (node1 % 1000 == 0) printf("\r...%dk, %dk", node1/1000, edges/1000);
  }
  return Graph;
}

Here is the call graph for this function:

PNGraph TKronMtx::GenFastKronecker	(	const TKronMtx &	SeedMtx,
		const int &	NIter,
		const bool &	IsDir,
		const int &	Seed = `0`
	)		`[static]`

Definition at line 349 of file kronecker.cpp.

References TVec< TVal >::Add(), TNGraph::AddEdge(), TNGraph::AddNode(), At(), GetDim(), GetEdges(), TNGraph::GetEdges(), GetMtxSum(), GetNodes(), TRnd::GetUniDev(), TNGraph::IsEdge(), MtxDim, New(), Rnd, and SeedMtx.

Referenced by TKroneckerLL::GradDescentConvergence(), PlotCmpGraphs(), TKronMaxLL::Test(), and TKroneckerLL::TestGradDescent().

                                                                                                                {
  const TKronMtx& SeedGraph = SeedMtx;
  const int MtxDim = SeedGraph.GetDim();
  const double MtxSum = SeedGraph.GetMtxSum();
  const int NNodes = SeedGraph.GetNodes(NIter);
  const int NEdges = SeedGraph.GetEdges(NIter);
  //const double DiagEdges = NNodes * pow(SeedGraph.At(0,0), double(NIter));
  //const int NEdges = (int) TMath::Round(((pow(double(SeedGraph.GetMtxSum()), double(NIter)) - DiagEdges) /2.0));
  printf("  FastKronecker: %d nodes, %d edges, %s...\n", NNodes, NEdges, IsDir ? "Directed":"UnDirected");
  PNGraph Graph = TNGraph::New(NNodes, -1);
  TRnd Rnd(Seed);
  TExeTm ExeTm;
  // prepare cell probability vector
  TVec<TFltIntIntTr> ProbToRCPosV; // row, col position
  double CumProb = 0.0;
  for (int r = 0; r < MtxDim; r++) {
    for (int c = 0; c < MtxDim; c++) {
      const double Prob = SeedGraph.At(r, c);
      if (Prob > 0.0) {
        CumProb += Prob;
        ProbToRCPosV.Add(TFltIntIntTr(CumProb/MtxSum, r, c));
      }
    }
  }
  // add nodes
  for (int i = 0; i < NNodes; i++) {
    Graph->AddNode(i); }
  // add edges
  int Rng, Row, Col, Collision=0, n = 0;
  for (int edges = 0; edges < NEdges; ) {
    Rng=NNodes;  Row=0;  Col=0;
    for (int iter = 0; iter < NIter; iter++) {
      const double& Prob = Rnd.GetUniDev();
      n = 0; while(Prob > ProbToRCPosV[n].Val1) { n++; }
      const int MtxRow = ProbToRCPosV[n].Val2;
      const int MtxCol = ProbToRCPosV[n].Val3;
      Rng /= MtxDim;
      Row += MtxRow * Rng;
      Col += MtxCol * Rng;
    }
    if (! Graph->IsEdge(Row, Col)) { // allow self-loops
      Graph->AddEdge(Row, Col);  edges++;
      if (! IsDir) {
        if (Row != Col) Graph->AddEdge(Col, Row);
        edges++;
      }
    } else { Collision++; }
    //if (edges % 1000 == 0) printf("\r...%dk", edges/1000);
  }
  //printf("             %d edges [%s]\n", Graph->GetEdges(), ExeTm.GetTmStr());
  printf("             collisions: %d (%.4f)\n", Collision, Collision/(double)Graph->GetEdges());
  return Graph;
}

Here is the call graph for this function:

Here is the caller graph for this function:

PNGraph TKronMtx::GenFastKronecker	(	const TKronMtx &	SeedMtx,
		const int &	NIter,
		const int &	Edges,
		const bool &	IsDir,
		const int &	Seed = `0`
	)		`[static]`

Definition at line 404 of file kronecker.cpp.

References TVec< TVal >::Add(), TNGraph::AddEdge(), TNGraph::AddNode(), At(), GetDim(), TNGraph::GetEdges(), GetMtxSum(), GetNodes(), TRnd::GetUniDev(), TNGraph::IsEdge(), MtxDim, New(), Rnd, and SeedMtx.

                                                                                                                                  {
  const TKronMtx& SeedGraph = SeedMtx;
  const int MtxDim = SeedGraph.GetDim();
  const double MtxSum = SeedGraph.GetMtxSum();
  const int NNodes = SeedGraph.GetNodes(NIter);
  const int NEdges = Edges;
  //const double DiagEdges = NNodes * pow(SeedGraph.At(0,0), double(NIter));
  //const int NEdges = (int) TMath::Round(((pow(double(SeedGraph.GetMtxSum()), double(NIter)) - DiagEdges) /2.0));
  printf("  RMat Kronecker: %d nodes, %d edges, %s...\n", NNodes, NEdges, IsDir ? "Directed":"UnDirected");
  PNGraph Graph = TNGraph::New(NNodes, -1);
  TRnd Rnd(Seed);
  TExeTm ExeTm;
  // prepare cell probability vector
  TVec<TFltIntIntTr> ProbToRCPosV; // row, col position
  double CumProb = 0.0;
  for (int r = 0; r < MtxDim; r++) {
    for (int c = 0; c < MtxDim; c++) {
      const double Prob = SeedGraph.At(r, c);
      if (Prob > 0.0) {
        CumProb += Prob;
        ProbToRCPosV.Add(TFltIntIntTr(CumProb/MtxSum, r, c));
      }
    }
  }
  // add nodes
  for (int i = 0; i < NNodes; i++) {
    Graph->AddNode(i); }
  // add edges
  int Rng, Row, Col, Collision=0, n = 0;
  for (int edges = 0; edges < NEdges; ) {
    Rng=NNodes;  Row=0;  Col=0;
    for (int iter = 0; iter < NIter; iter++) {
      const double& Prob = Rnd.GetUniDev();
      n = 0; while(Prob > ProbToRCPosV[n].Val1) { n++; }
      const int MtxRow = ProbToRCPosV[n].Val2;
      const int MtxCol = ProbToRCPosV[n].Val3;
      Rng /= MtxDim;
      Row += MtxRow * Rng;
      Col += MtxCol * Rng;
    }
    if (! Graph->IsEdge(Row, Col)) { // allow self-loops
      Graph->AddEdge(Row, Col);  edges++;
      if (! IsDir) {
        if (Row != Col) Graph->AddEdge(Col, Row);
        edges++;
      }
    } else { Collision++; }
    //if (edges % 1000 == 0) printf("\r...%dk", edges/1000);
  }
  //printf("             %d edges [%s]\n", Graph->GetEdges(), ExeTm.GetTmStr());
  printf("             collisions: %d (%.4f)\n", Collision, Collision/(double)Graph->GetEdges());
  return Graph;
}

Here is the call graph for this function:

PNGraph TKronMtx::GenKronecker	(	const TKronMtx &	SeedMtx,
		const int &	NIter,
		const bool &	IsDir,
		const int &	Seed = `0`
	)		`[static]`

Definition at line 312 of file kronecker.cpp.

References TNGraph::AddEdge(), TNGraph::AddNode(), TNGraph::GetEdges(), GetNodes(), TExeTm::GetTmStr(), TRnd::GetUniDev(), IsEdgePlace(), New(), Rnd, and SeedMtx.

Referenced by PlotCmpGraphs().

                                                                                                            {
  const TKronMtx& SeedGraph = SeedMtx;
  const int NNodes = SeedGraph.GetNodes(NIter);
  printf("  Kronecker: %d nodes, %s...\n", NNodes, IsDir ? "Directed":"UnDirected");
  PNGraph Graph = TNGraph::New(NNodes, -1);
  TExeTm ExeTm;
  TRnd Rnd(Seed);
  int edges = 0;
  for (int node1 = 0; node1 < NNodes; node1++) {
    Graph->AddNode(node1); }
  if (IsDir) {
    for (int node1 = 0; node1 < NNodes; node1++) {
      for (int node2 = 0; node2 < NNodes; node2++) {
        if (SeedGraph.IsEdgePlace(node1, node2, NIter, Rnd.GetUniDev())) {
          Graph->AddEdge(node1, node2);
          edges++;
        }
      }
      if (node1 % 1000 == 0) printf("\r...%dk, %dk", node1/1000, edges/1000);
    }
  } else {
    for (int node1 = 0; node1 < NNodes; node1++) {
      for (int node2 = node1; node2 < NNodes; node2++) {
        if (SeedGraph.IsEdgePlace(node1, node2, NIter, Rnd.GetUniDev())) {
          Graph->AddEdge(node1, node2);
          Graph->AddEdge(node2, node1);
          edges++;
        }
      }
      if (node1 % 1000 == 0) printf("\r...%dk, %dk", node1/1000, edges/1000);
    }
  }
  printf("\r             %d edges [%s]\n", Graph->GetEdges(), ExeTm.GetTmStr());
  return Graph;
}

Here is the call graph for this function:

Here is the caller graph for this function:

void TKronMtx::GenMtx ( const int & Dim ) [inline]

Definition at line 40 of file kronecker.h.

References TVec< TVal >::Gen(), MtxDim, and SeedMtx.

Referenced by GetLLMtx(), GetProbMtx(), KronMul(), KronSum(), and TKronMaxLL::RoundTheta().

{ MtxDim=Dim;  SeedMtx.Gen(Dim*Dim); }

Here is the call graph for this function:

Here is the caller graph for this function:

PNGraph TKronMtx::GenRndGraph ( const double & RndFact = 1.0 ) const

Definition at line 295 of file kronecker.cpp.

References TNGraph::AddEdge(), TNGraph::AddNode(), At(), GetDim(), TRnd::GetUniDev(), and New().

                                                         {
  PNGraph Graph = TNGraph::New();
  for (int i = 0; i < GetDim(); i++) {
    Graph->AddNode(i); }
  for (int r = 0; r < GetDim(); r++) {
    for (int c = 0; c < GetDim(); c++) {
      if (RndFact * At(r, c) >= TKronMtx::Rnd.GetUniDev()) { Graph->AddEdge(r, c); }
    }
  }
  return Graph;
}

Here is the call graph for this function:

PNGraph TKronMtx::GenThreshGraph ( const double & Thresh ) const

Definition at line 283 of file kronecker.cpp.

References TNGraph::AddEdge(), TNGraph::AddNode(), At(), GetDim(), and New().

                                                           {
  PNGraph Graph = TNGraph::New();
  for (int i = 0; i < GetDim(); i++) {
    Graph->AddNode(i); }
  for (int r = 0; r < GetDim(); r++) {
    for (int c = 0; c < GetDim(); c++) {
      if (At(r, c) >= Thresh) { Graph->AddEdge(r, c); }
    }
  }
  return Graph;
}

Here is the call graph for this function:

double TKronMtx::GetApxNoEdgeDLL	(	const int &	ParamId,
		int	NId1,
		int	NId2,
		const int &	NKronIters
	)		const

Definition at line 240 of file kronecker.cpp.

References At(), GetDim(), IAssert, MtxDim, and NInf.

Referenced by TKroneckerLL::CalcApxGraphDLL(), TKroneckerLL::CalcFullApxGraphDLL(), TKroneckerLL::MetroGibbsSampleNext(), TKroneckerLL::NodeDLLDelta(), and TKroneckerLL::UpdateGraphDLL().

                                                                                                    {
  const int& ThetaX = ParamId % GetDim();
  const int& ThetaY = ParamId / GetDim();
  int ThetaCnt = 0;
  double DLL = 0;//, LL = 0;
  for (int level = 0; level < NKronIters; level++) {
    const int X = NId1 % MtxDim;
    const int Y = NId2 % MtxDim;
    const double LVal = At(X, Y); IAssert(LVal > NInf);
    if (X == ThetaX && Y == ThetaY) {
      if (ThetaCnt != 0) { DLL += LVal; }
      ThetaCnt++;
    } else { DLL += LVal; }
    //LL += LVal;
    NId1 /= MtxDim;  NId2 /= MtxDim;
  }
  //return -ThetaCnt*exp(DLL)*(1.0 + exp(LL)); // -x'/(1+x) WRONG!
  // deriv = -(ax^(a-1)*y^b..) - a*x^(2a-1)*y^2b..
  //       = - (ax^(a-1)*y^b..) - a*x*(x^(a-1)*y^b..)^2
  return -ThetaCnt*exp(DLL) - ThetaCnt*exp(At(ThetaX, ThetaY)+2*DLL);
}

Here is the call graph for this function:

Here is the caller graph for this function:

double TKronMtx::GetApxNoEdgeLL	(	int	NId1,
		int	NId2,
		const int &	NKronIters
	)		const

Definition at line 191 of file kronecker.cpp.

References GetEdgeLL().

Referenced by TKroneckerLL::CalcApxGraphLL(), TKroneckerLL::MetroGibbsSampleNext(), TKroneckerLL::NodeLLDelta(), and TKroneckerLL::SwapNodesLL().

                                                                               {
  const double EdgeLL = GetEdgeLL(NId1, NId2, NKronIters);
  return -exp(EdgeLL) - 0.5*exp(2*EdgeLL);
}

Here is the call graph for this function:

Here is the caller graph for this function:

double TKronMtx::GetAvgAbsErr	(	const TKronMtx &	Kron1,
		const TKronMtx &	Kron2
	)		`[static]`

Definition at line 655 of file kronecker.cpp.

References GetMtx(), IAssert, TVec< TVal >::Len(), and TVec< TVal >::Sort().

Referenced by TKroneckerLL::GradDescentConvergence(), and TKroneckerLL::TestKronDescent().

                                                                          {
  TFltV P1 = Kron1.GetMtx();
  TFltV P2 = Kron2.GetMtx();
  IAssert(P1.Len() == P2.Len());
  P1.Sort();  P2.Sort();
  double delta = 0.0;
  for (int i = 0; i < P1.Len(); i++) {
    delta += fabs(P1[i] - P2[i]);
  }
  return delta/P1.Len();
}

Here is the call graph for this function:

Here is the caller graph for this function:

double TKronMtx::GetAvgFroErr	(	const TKronMtx &	Kron1,
		const TKronMtx &	Kron2
	)		`[static]`

Definition at line 668 of file kronecker.cpp.

References GetMtx(), IAssert, TVec< TVal >::Len(), and TVec< TVal >::Sort().

                                                                          {
  TFltV P1 = Kron1.GetMtx();
  TFltV P2 = Kron2.GetMtx();
  IAssert(P1.Len() == P2.Len());
  P1.Sort();  P2.Sort();
  double delta = 0.0;
  for (int i = 0; i < P1.Len(); i++) {
    delta += pow(P1[i] - P2[i], 2);
  }
  return sqrt(delta/P1.Len());
}

Here is the call graph for this function:

double TKronMtx::GetColSum ( const int & ColId ) const

Definition at line 154 of file kronecker.cpp.

References At(), and GetDim().

Referenced by TKroneckerLL::GetFullColLL().

                                                 {
  double Sum = 0;
  for (int r = 0; r < GetDim(); r++) {
    Sum += At(r, ColId); }
  return Sum;
}

Here is the call graph for this function:

Here is the caller graph for this function:

int TKronMtx::GetDim ( ) const [inline]

Definition at line 30 of file kronecker.h.

References MtxDim.

Referenced by TKroneckerLL::AppendIsoNodes(), Dump(), GenFastKronecker(), GenRndGraph(), GenThreshGraph(), GetApxNoEdgeDLL(), GetColSum(), TKroneckerLL::GetDim(), GetEdgeDLL(), GetEdgeProb(), TKroneckerLL::GetFullColLL(), TKroneckerLL::GetFullGraphLL(), TKroneckerLL::GetFullRowLL(), GetKronIter(), GetMtxStr(), GetNodes(), GetNoEdgeDLL(), GetRowSum(), KronMul(), KronSum(), TKroneckerLL::MetroGibbsSampleSetup(), TKroneckerLL::RunMStep(), SaveTxt(), TKroneckerLL::SetBestDegPerm(), TKroneckerLL::SetGraph(), and TKroneckerLL::SetRandomEdges().

{ return MtxDim; }

Here is the caller graph for this function:

double TKronMtx::GetEdgeDLL	(	const int &	ParamId,
		int	NId1,
		int	NId2,
		const int &	NKronIters
	)		const

Definition at line 207 of file kronecker.cpp.

References At(), GetDim(), and MtxDim.

Referenced by TKroneckerLL::CalcApxGraphDLL(), TKroneckerLL::CalcFullApxGraphDLL(), TKroneckerLL::CalcGraphDLL(), TKroneckerLL::MetroGibbsSampleNext(), TKroneckerLL::NodeDLLDelta(), and TKroneckerLL::UpdateGraphDLL().

                                                                                               {
  const int ThetaX = ParamId % GetDim();
  const int ThetaY = ParamId / GetDim();
  int ThetaCnt = 0;
  for (int level = 0; level < NKronIters; level++) {
    if ((NId1 % MtxDim) == ThetaX && (NId2 % MtxDim) == ThetaY) {
      ThetaCnt++; }
    NId1 /= MtxDim;  NId2 /= MtxDim;
  }
  return double(ThetaCnt) / exp(At(ParamId));
}

Here is the call graph for this function:

Here is the caller graph for this function:

double TKronMtx::GetEdgeLL	(	int	NId1,
		int	NId2,
		const int &	NKronIters
	)		const

Definition at line 175 of file kronecker.cpp.

References At(), MtxDim, and NInf.

Referenced by TKroneckerLL::CalcApxGraphLL(), TKroneckerLL::CalcGraphLL(), GetApxNoEdgeLL(), GetNoEdgeLL(), TKroneckerLL::MetroGibbsSampleNext(), TKroneckerLL::NodeLLDelta(), and TKroneckerLL::SwapNodesLL().

                                                                          {
  double LL = 0.0;
  for (int level = 0; level < NKronIters; level++) {
    const double& LLVal = At(NId1 % MtxDim, NId2 % MtxDim);
    if (LLVal == NInf) return NInf;
    LL += LLVal;
    NId1 /= MtxDim;  NId2 /= MtxDim;
  }
  return LL;
}

Here is the call graph for this function:

Here is the caller graph for this function:

double TKronMtx::GetEdgeProb	(	int	NId1,
		int	NId2,
		const int &	NKronIters
	)		const

Definition at line 161 of file kronecker.cpp.

References At(), and MtxDim.

Referenced by GetNoEdgeProb().

                                                                            {
  double Prob = 1.0;
  for (int level = 0; level < NKronIters; level++) {
    Prob *= At(NId1 % MtxDim, NId2 % MtxDim);
    if (Prob == 0.0) { return 0.0; }
    NId1 /= MtxDim;  NId2 /= MtxDim;
  }
  return Prob;
}

Here is the call graph for this function:

Here is the caller graph for this function:

double TKronMtx::GetEdgeProb	(	const uint &	NId1Sig,
		const uint &	NId2Sig,
		const int &	NIter
	)		const

Definition at line 271 of file kronecker.cpp.

References Assert, At(), and GetDim().

                                                                                             {
  Assert(GetDim() == 2);
  double Prob = 1.0;
  for (int i = 0; i < NIter; i++) {
    const uint Mask = (1u<<i);
    const uint Bit1 = NId1Sig & Mask;
    const uint Bit2 = NId2Sig & Mask;
    Prob *= At(int(Bit1!=0), int(Bit2!=0));
  }
  return Prob;
}

Here is the call graph for this function:

int TKronMtx::GetEdges ( const int & NIter ) const

Definition at line 123 of file kronecker.cpp.

References GetMtxSum().

Referenced by GenFastKronecker(), TKroneckerLL::GradDescent(), TKroneckerLL::GradDescent2(), and TKroneckerLL::GradDescentConvergence().

                                             {
  return (int) pow(double(GetMtxSum()), double(NIter));
}

Here is the call graph for this function:

Here is the caller graph for this function:

double TKronMtx::GetEZero	(	const int &	Edges,
		const int &	KronIter
	)		const

Definition at line 136 of file kronecker.cpp.

                                                                      {
  return pow((double) Edges, 1.0/double(KronIters));
}

TKronMtx TKronMtx::GetInitMtx	(	const int &	Dim,
		const int &	Nodes,
		const int &	Edges
	)		`[static]`

Definition at line 705 of file kronecker.cpp.

References TRnd::GetUniDev(), TVec< TVal >::Len(), TVec< TVal >::PutAll(), and SetForEdges().

Referenced by GetInitMtx(), and TKroneckerLL::TestBicCriterion().

                                                                                {
  const double MxParam = 0.8+TKronMtx::Rnd.GetUniDev()/5.0;
  const double MnParam = 0.2-TKronMtx::Rnd.GetUniDev()/5.0;
  const double Step = (MxParam-MnParam) / (Dim*Dim-1);
  TFltV ParamV(Dim*Dim);
  if (Dim == 1) { ParamV.PutAll(0.5); } // random graph
  else {
    for (int p = 0; p < ParamV.Len(); p++) {
      ParamV[p] = MxParam - p*Step; }
  }
  //IAssert(ParamV[0]==MxParam && ParamV.Last()==MnParam);
  TKronMtx Mtx(ParamV);
  Mtx.SetForEdges(Nodes, Edges);
  return Mtx;
}

Here is the call graph for this function:

Here is the caller graph for this function:

TKronMtx TKronMtx::GetInitMtx	(	const TStr &	MtxStr,
		const int &	Dim,
		const int &	Nodes,
		const int &	Edges
	)		`[static]`

Definition at line 721 of file kronecker.cpp.

References AddRndNoise(), At(), FailR, GetInitMtx(), GetMtx(), GetRndMtx(), TRnd::GetUniDev(), TCh::IsNum(), and SetForEdges().

                                                                                                    {
  TKronMtx Mtx(Dim);
  if (TCh::IsNum(MtxStr[0])) { Mtx = TKronMtx::GetMtx(MtxStr); }
  else if (MtxStr[0] == 'r') { Mtx = TKronMtx::GetRndMtx(Dim, 0.1); }
  else if (MtxStr[0] == 'a') {
    const double Prob = TKronMtx::Rnd.GetUniDev();
    if (Prob < 0.4) {
      Mtx = TKronMtx::GetInitMtx(Dim, Nodes, Edges); }
    else { // interpolate so that there are in the corners 0.9, 0.5, 0.1, 0.5
      const double Max = 0.9+TKronMtx::Rnd.GetUniDev()/10.0;
      const double Min = 0.1-TKronMtx::Rnd.GetUniDev()/10.0;
      const double Med = (Max-Min)/2.0;
      Mtx.At(0,0)      = Max;       Mtx.At(0,Dim-1) = Med;
      Mtx.At(Dim-1, 0) = Med;  Mtx.At(Dim-1, Dim-1) = Min;
      for (int i = 1; i < Dim-1; i++) {
        Mtx.At(i,i) = Max - double(i)*(Max-Min)/double(Dim-1);
        Mtx.At(i, 0) = Mtx.At(0, i) = Max - double(i)*(Max-Med)/double(Dim-1);
        Mtx.At(i, Dim-1) = Mtx.At(Dim-1, i) = Med - double(i)*(Med-Min)/double(Dim-1);
      }
      for (int i = 1; i < Dim-1; i++) {
        for (int j = 1; j < Dim-1; j++) {
          if (i >= j) { continue; }
          Mtx.At(i,j) = Mtx.At(j,i) = Mtx.At(i,i) - (j-i)*(Mtx.At(i,i)-Mtx.At(i,Dim-1))/(Dim-i-1);
        }
      }
      Mtx.AddRndNoise(0.1);
    }
  } else { FailR("Wrong mtx: matlab str, or random (r), or all (a)"); }
  Mtx.SetForEdges(Nodes, Edges);
  return Mtx;
}

Here is the call graph for this function:

int TKronMtx::GetKronIter ( const int & Nodes ) const

Definition at line 127 of file kronecker.cpp.

References GetDim().

Referenced by GetNZeroK(), PlotCmpGraphs(), SetForEdges(), and TKronMomentsFit::Test().

                                                {
  return (int) ceil(log(double(Nodes)) / log(double(GetDim()))); // upper bound
  //return (int) TMath::Round(log(double(Nodes)) / log(double(GetDim()))); // round to nearest power
}

Here is the call graph for this function:

Here is the caller graph for this function:

int TKronMtx::GetKronIter	(	const int &	GNodes,
		const int &	SeedMtxSz
	)		`[static]`

Definition at line 307 of file kronecker.cpp.

                                                                 {
  return (int) ceil(log(double(GNodes)) / log(double(SeedMtxSz)));
}

void TKronMtx::GetLLMtx ( TKronMtx & LLMtx )

Definition at line 98 of file kronecker.cpp.

References At(), GenMtx(), Len(), MtxDim, and NInf.

Referenced by TKroneckerLL::GradDescent(), TKroneckerLL::GradDescent2(), TKroneckerLL::GradDescentConvergence(), TKroneckerLL::InitLL(), TKroneckerLL::RunMStep(), and TKroneckerLL::TestKronDescent().

                                       {
  LLMtx.GenMtx(MtxDim);
  for (int i = 0; i < Len(); i++) {
    if (At(i) != 0.0) { LLMtx.At(i) = log(At(i)); }
    else { LLMtx.At(i) = NInf; }
  }
}

Here is the call graph for this function:

Here is the caller graph for this function:

TFltV& TKronMtx::GetMtx ( ) [inline]

Definition at line 35 of file kronecker.h.

References SeedMtx.

Referenced by GetAvgAbsErr(), GetAvgFroErr(), GetInitMtx(), GetMtxFromNm(), TKronMaxLL::Test(), and TKroneckerLL::TestGradDescent().

{ return SeedMtx; }

Here is the caller graph for this function:

const TFltV& TKronMtx::GetMtx ( ) const [inline]

Definition at line 36 of file kronecker.h.

References SeedMtx.

{ return SeedMtx; }

TKronMtx TKronMtx::GetMtx ( TStr MatlabMtxStr ) [static]

Definition at line 681 of file kronecker.cpp.

References At(), TStr::ChangeChAll(), TVec< TVal >::Empty(), GetFlt(), IAssert, TVec< TVal >::Len(), and TStr::SplitOnAllCh().

                                           {
  TStrV RowStrV, ColStrV;
  MatlabMtxStr.ChangeChAll(',', ' ');
  MatlabMtxStr.SplitOnAllCh(';', RowStrV);  IAssert(! RowStrV.Empty());
  RowStrV[0].SplitOnWs(ColStrV);    IAssert(! ColStrV.Empty());
  const int Rows = RowStrV.Len();
  const int Cols = ColStrV.Len();
  IAssert(Rows == Cols);
  TKronMtx Mtx(Rows);
  for (int r = 0; r < Rows; r++) {
    RowStrV[r].SplitOnWs(ColStrV);
    IAssert(ColStrV.Len() == Cols);
    for (int c = 0; c < Cols; c++) {
      Mtx.At(r, c) = (double) ColStrV[c].GetFlt(); }
  }
  return Mtx;
}

Here is the call graph for this function:

TKronMtx TKronMtx::GetMtxFromNm ( const TStr & MtxNm ) [static]

Definition at line 753 of file kronecker.cpp.

References TStr::CStr(), FailR, TStr::Fmt(), GetMtx(), and TKronMtx().

                                                 {
  if (MtxNm == "3chain") return TKronMtx::GetMtx("1 1 0; 1 1 1; 0 1 1");
  else if (MtxNm == "4star") return TKronMtx::GetMtx("1 1 1 1; 1 1 0 0 ; 1 0 1 0; 1 0 0 1");
  else if (MtxNm == "4chain") return TKronMtx::GetMtx("1 1 0 0; 1 1 1 0 ; 0 1 1 1; 0 0 1 1");
  else if (MtxNm == "4square") return TKronMtx::GetMtx("1 1 0 1; 1 1 1 0 ; 0 1 1 1; 1 0 1 1");
  else if (MtxNm == "5star") return TKronMtx::GetMtx("1 1 1 1 1; 1 1 0 0 0; 1 0 1 0 0; 1 0 0 1 0; 1 0 0 0 1");
  else if (MtxNm == "6star") return TKronMtx::GetMtx("1 1 1 1 1 1; 1 1 0 0 0 0; 1 0 1 0 0 0; 1 0 0 1 0 0; 1 0 0 0 1 0; 1 0 0 0 0 1");
  else if (MtxNm == "7star") return TKronMtx::GetMtx("1 1 1 1 1 1 1; 1 1 0 0 0 0 0; 1 0 1 0 0 0 0; 1 0 0 1 0 0 0; 1 0 0 0 1 0 0; 1 0 0 0 0 1 0; 1 0 0 0 0 0 1");
  else if (MtxNm == "5burst") return TKronMtx::GetMtx("1 1 1 1 0; 1 1 0 0 0; 1 0 1 0 0; 1 0 0 1 1; 0 0 0 1 1");
  else if (MtxNm == "7burst") return TKronMtx::GetMtx("1 0 0 1 0 0 0; 0 1 0 1 0 0 0; 0 0 1 1 0 0 0; 1 1 1 1 1 0 0; 0 0 0 1 1 1 1; 0 0 0 0 1 1 0; 0 0 0 0 1 0 1");
  else if (MtxNm == "7cross") return TKronMtx::GetMtx("1 0 0 1 0 0 0; 0 1 0 1 0 0 0; 0 0 1 1 0 0 0; 1 1 1 1 1 0 0; 0 0 0 1 1 1 0; 0 0 0 0 1 1 1; 0 0 0 0 0 1 1");
  FailR(TStr::Fmt("Unknow matrix: '%s'", MtxNm.CStr()).CStr());
  return TKronMtx();
}

Here is the call graph for this function:

TStr TKronMtx::GetMtxStr ( ) const

Definition at line 80 of file kronecker.cpp.

References At(), TStr::Fmt(), GetDim(), and Len().

Referenced by PlotCmpGraphs().

                               {
  TChA ChA("[");
  for (int i = 0; i < Len(); i++) {
    ChA += TStr::Fmt("%g", At(i));
    if ((i+1)%GetDim()==0 && (i+1<Len())) { ChA += "; "; }
    else if (i+1<Len()) { ChA += ", "; }
  }
  ChA += "]";
  return TStr(ChA);
}

Here is the call graph for this function:

Here is the caller graph for this function:

double TKronMtx::GetMtxSum ( ) const

Definition at line 140 of file kronecker.cpp.

References At(), and Len().

Referenced by GenFastKronecker(), TKroneckerLL::GetAbsErr(), GetEdges(), TKroneckerLL::GetFullGraphLL(), TKroneckerLL::GradDescent(), TKroneckerLL::GradDescent2(), TKroneckerLL::GradDescentConvergence(), TKroneckerLL::MetroGibbsSampleSetup(), TKroneckerLL::RunMStep(), SetForEdges(), TKroneckerLL::SetRandomEdges(), and TKroneckerLL::TestKronDescent().

                                 {
  double Sum = 0;
  for (int i = 0; i < Len(); i++) {
    Sum += At(i); }
  return Sum;
}

Here is the call graph for this function:

Here is the caller graph for this function:

int TKronMtx::GetNodes ( const int & NIter ) const

Definition at line 119 of file kronecker.cpp.

References GetDim().

Referenced by GenDetKronecker(), GenFastKronecker(), GenKronecker(), TKroneckerLL::GetEmptyGraphLL(), GetNZeroK(), TKroneckerLL::GradDescent(), TKroneckerLL::GradDescent2(), TKroneckerLL::GradDescentConvergence(), and TKroneckerLL::RunKronEM().

                                             {
  return (int) pow(double(GetDim()), double(NIter));
}

Here is the call graph for this function:

Here is the caller graph for this function:

uint TKronMtx::GetNodeSig ( const double & OneProb = 0.5 ) [static]

Definition at line 262 of file kronecker.cpp.

References Sig.

                                               {
  uint Sig = 0;
  for (int i = 0; i < (int)(8*sizeof(uint)); i++) {
    if (TKronMtx::Rnd.GetUniDev() < OneProb) {
      Sig |= (1u<<i); }
  }
  return Sig;
}

double TKronMtx::GetNoEdgeDLL	(	const int &	ParamId,
		int	NId1,
		int	NId2,
		const int &	NKronIters
	)		const

Definition at line 220 of file kronecker.cpp.

References At(), GetDim(), and MtxDim.

Referenced by TKroneckerLL::CalcGraphDLL(), and TKroneckerLL::GetEmptyGraphDLL().

                                                                                                 {
  const int& ThetaX = ParamId % GetDim();
  const int& ThetaY = ParamId / GetDim();
  int ThetaCnt = 0;
  double DLL = 0, LL = 0;
  for (int level = 0; level < NKronIters; level++) {
    const int X = NId1 % MtxDim;
    const int Y = NId2 % MtxDim;
    const double LVal = At(X, Y);
    if (X == ThetaX && Y == ThetaY) {
      if (ThetaCnt != 0) { DLL += LVal; }
      ThetaCnt++;
    } else { DLL += LVal; }
    LL += LVal;
    NId1 /= MtxDim;  NId2 /= MtxDim;
  }
  return -ThetaCnt*exp(DLL) / (1.0 - exp(LL));
}

Here is the call graph for this function:

Here is the caller graph for this function:

double TKronMtx::GetNoEdgeLL	(	int	NId1,
		int	NId2,
		const int &	NKronIters
	)		const

Definition at line 186 of file kronecker.cpp.

References GetEdgeLL().

Referenced by TKroneckerLL::CalcGraphLL(), and TKroneckerLL::GetEmptyGraphLL().

                                                                            {
  return log(1.0 - exp(GetEdgeLL(NId1, NId2, NKronIters)));
}

Here is the call graph for this function:

Here is the caller graph for this function:

double TKronMtx::GetNoEdgeProb	(	int	NId1,
		int	NId2,
		const int &	NKronIters
	)		const

Definition at line 171 of file kronecker.cpp.

References GetEdgeProb().

                                                                              {
  return 1.0 - GetEdgeProb(NId1, NId2, NKronIters);
}

Here is the call graph for this function:

int TKronMtx::GetNZeroK ( const PNGraph & Graph ) const

Definition at line 132 of file kronecker.cpp.

References GetKronIter(), GetNodes(), and TNGraph::GetNodes().

                                                  {
 return GetNodes(GetKronIter(Graph->GetNodes()));
}

Here is the call graph for this function:

int TKronMtx::GetPrimHashCd ( ) const [inline]

Definition at line 26 of file kronecker.h.

References TVec< TVal >::GetPrimHashCd(), and SeedMtx.

{ return SeedMtx.GetPrimHashCd(); }

Here is the call graph for this function:

void TKronMtx::GetProbMtx ( TKronMtx & ProbMtx )

Definition at line 106 of file kronecker.cpp.

References At(), GenMtx(), Len(), MtxDim, and NInf.

                                           {
  ProbMtx.GenMtx(MtxDim);
  for (int i = 0; i < Len(); i++) {
    if (At(i) != NInf) { ProbMtx.At(i) = exp(At(i)); }
    else { ProbMtx.At(i) = 0.0; }
  }
}

Here is the call graph for this function:

TKronMtx TKronMtx::GetRndMtx	(	const int &	Dim,
		const double &	MinProb
	)		`[static]`

Definition at line 699 of file kronecker.cpp.

References SetRndMtx().

Referenced by GetInitMtx().

                                                                  {
  TKronMtx Mtx;
  Mtx.SetRndMtx(Dim, MinProb);
  return Mtx;
}

Here is the call graph for this function:

Here is the caller graph for this function:

double TKronMtx::GetRowSum ( const int & RowId ) const

Definition at line 147 of file kronecker.cpp.

References At(), and GetDim().

Referenced by TKroneckerLL::GetFullRowLL().

                                                 {
  double Sum = 0;
  for (int c = 0; c < GetDim(); c++) {
    Sum += At(RowId, c); }
  return Sum;
}

Here is the call graph for this function:

Here is the caller graph for this function:

int TKronMtx::GetSecHashCd ( ) const [inline]

Definition at line 27 of file kronecker.h.

References TVec< TVal >::GetSecHashCd(), and SeedMtx.

{ return SeedMtx.GetSecHashCd(); }

Here is the call graph for this function:

bool TKronMtx::IsEdgePlace	(	int	NId1,
		int	NId2,
		const int &	NKronIters,
		const double &	ProbTresh
	)		const

Definition at line 196 of file kronecker.cpp.

References At(), and MtxDim.

Referenced by GenDetKronecker(), and GenKronecker().

                                                                                                   {
  double Prob = 1.0;
  for (int level = 0; level < NKronIters; level++) {
    Prob *= At(NId1 % MtxDim, NId2 % MtxDim);
    if (ProbTresh > Prob) { return false; }
    NId1 /= MtxDim;  NId2 /= MtxDim;
  }
  return true;
}

Here is the call graph for this function:

Here is the caller graph for this function:

bool TKronMtx::IsProbMtx ( ) const

Definition at line 33 of file kronecker.cpp.

References At(), and Len().

Referenced by TKroneckerLL::InitLL().

                               {
  for (int i = 0; i < Len(); i++) {
    if (At(i) < 0.0 || At(i) > 1.0) return false;
  }
  return true;
}

Here is the call graph for this function:

Here is the caller graph for this function:

void TKronMtx::KronMul	(	const TKronMtx &	LeftPt,
		const TKronMtx &	RightPt,
		TKronMtx &	OutMtx
	)		`[static]`

Definition at line 591 of file kronecker.cpp.

References At(), GenMtx(), and GetDim().

Referenced by KronPwr().

                                                                                    {
  const int LDim = Left.GetDim();
  const int RDim = Right.GetDim();
  Result.GenMtx(LDim * RDim);
  for (int r1 = 0; r1 < LDim; r1++) {
    for (int c1 = 0; c1 < LDim; c1++) {
      const double& Val = Left.At(r1, c1);
      for (int r2 = 0; r2 < RDim; r2++) {
        for (int c2 = 0; c2 < RDim; c2++) {
          Result.At(r1*RDim+r2, c1*RDim+c2) = Val * Right.At(r2, c2);
        }
      }
    }
  }
}

Here is the call graph for this function:

Here is the caller graph for this function:

void TKronMtx::KronPwr	(	const TKronMtx &	KronPt,
		const int &	NIter,
		TKronMtx &	OutMtx
	)		`[static]`

Definition at line 626 of file kronecker.cpp.

References KronMul(), and Swap().

                                                                                  {
  OutMtx = KronMtx;
  TKronMtx NewOutMtx;
  for (int iter = 0; iter < NIter; iter++) {
    KronMul(OutMtx, KronMtx, NewOutMtx);
    NewOutMtx.Swap(OutMtx);
  }

}

Here is the call graph for this function:

void TKronMtx::KronSum	(	const TKronMtx &	LeftPt,
		const TKronMtx &	RightPt,
		TKronMtx &	OutMtx
	)		`[static]`

Definition at line 607 of file kronecker.cpp.

References At(), GenMtx(), GetDim(), and NInf.

                                                                                    {
  const int LDim = Left.GetDim();
  const int RDim = Right.GetDim();
  Result.GenMtx(LDim * RDim);
  for (int r1 = 0; r1 < LDim; r1++) {
    for (int c1 = 0; c1 < LDim; c1++) {
      const double& Val = Left.At(r1, c1);
      for (int r2 = 0; r2 < RDim; r2++) {
        for (int c2 = 0; c2 < RDim; c2++) {
          if (Val == NInf || Right.At(r2, c2) == NInf) {
            Result.At(r1*RDim+r2, c1*RDim+c2) = NInf; }
          else {
            Result.At(r1*RDim+r2, c1*RDim+c2) = Val + Right.At(r2, c2); }
        }
      }
    }
  }
}

Here is the call graph for this function:

int TKronMtx::Len ( ) const [inline]

Definition at line 31 of file kronecker.h.

References TVec< TVal >::Len(), and SeedMtx.

Referenced by AddRndNoise(), TKroneckerLL::CalcApxGraphDLL(), TKroneckerLL::CalcFullApxGraphDLL(), TKroneckerLL::CalcGraphDLL(), TKroneckerLL::GetApxEmptyGraphDLL(), TKroneckerLL::GetApxEmptyGraphLL(), GetLLMtx(), GetMtxStr(), GetMtxSum(), TKroneckerLL::GetParams(), GetProbMtx(), IsProbMtx(), TKroneckerLL::MetroGibbsSampleNext(), TKroneckerLL::SampleGradient(), SetEpsMtx(), SetForEdges(), TKroneckerLL::SetGraph(), ToOneMinusMtx(), and TKroneckerLL::UpdateGraphDLL().

{ return SeedMtx.Len(); }

Here is the call graph for this function:

Here is the caller graph for this function:

TKronMtx TKronMtx::LoadTxt ( const TStr & MtxFNm ) [static]

Definition at line 768 of file kronecker.cpp.

References At(), IAssert, IAssertR, and ssfTabSep.

                                             {
  PSs Ss = TSs::LoadTxt(ssfTabSep, MtxFNm);
  IAssertR(Ss->GetXLen() == Ss->GetYLen(), "Not a square matrix");
  IAssert(Ss->GetYLen() == Ss->GetXLen());
  TKronMtx Mtx(Ss->GetYLen());
  for (int r = 0; r < Ss->GetYLen(); r++) {
    for (int c = 0; c < Ss->GetXLen(); c++) {
      Mtx.At(r, c) = (double) Ss->At(c, r).GetFlt(); }
  }
  return Mtx;
}

Here is the call graph for this function:

TKronMtx & TKronMtx::operator= ( const TKronMtx & Kronecker )

Definition at line 25 of file kronecker.cpp.

References MtxDim, and SeedMtx.

                                                         {
  if (this != &Kronecker){
    MtxDim=Kronecker.MtxDim;
    SeedMtx=Kronecker.SeedMtx;
  }
  return *this;
}

bool TKronMtx::operator== ( const TKronMtx & Kronecker ) const [inline]

Definition at line 25 of file kronecker.h.

References SeedMtx.

{ return SeedMtx==Kronecker.SeedMtx; }

void TKronMtx::PlotCmpGraphs	(	const TKronMtx &	SeedMtx,
		const PNGraph &	Graph,
		const TStr &	OutFNm,
		const TStr &	Desc
	)		`[static]`

Definition at line 479 of file kronecker.cpp.

References TStr::CStr(), TSnap::DelZeroDegNodes(), TStr::Fmt(), GenFastKronecker(), GenKronecker(), TNGraph::GetEdges(), GetKronIter(), TSnap::GetMxWcc(), TNGraph::GetNodes(), gpwLinesPoints, gsdClustCf, gsdHops, gsdInDeg, gsdOutDeg, gsdScc, gsdSngVal, gsdSngVec, gsdWcc, and tmuNodes.

                                                                                                                 {
  const int KronIters = SeedMtx.GetKronIter(Graph->GetNodes());
  PNGraph KronG, WccG;
  const bool FastGen = true;
  if (FastGen) { KronG = TKronMtx::GenFastKronecker(SeedMtx, KronIters, true, 0); }
  else { KronG = TKronMtx::GenKronecker(SeedMtx, KronIters, true, 0); }
  TSnap::DelZeroDegNodes(KronG);
  WccG = TSnap::GetMxWcc(KronG);
  const TStr Desc1 = TStr::Fmt("%s", Desc.CStr());
  TGStatVec GS(tmuNodes, TFSet() | gsdInDeg | gsdOutDeg | gsdWcc | gsdHops | gsdScc | gsdClustCf | gsdSngVec | gsdSngVal);
  //gsdHops
  //gsWccHops, gsdSngVal, gsdSngVec, gsdClustCf
  GS.Add(Graph, TSecTm(1), TStr::Fmt("GRAPH  G(%d, %d)", Graph->GetNodes(), Graph->GetEdges()));
  GS.Add(KronG, TSecTm(2), TStr::Fmt("KRONECKER  K(%d, %d)", KronG->GetNodes(), KronG->GetEdges()));
  GS.Add(WccG, TSecTm(3),  TStr::Fmt("KRONECKER  wccK(%d, %d)", WccG->GetNodes(), WccG->GetEdges()));
  const TStr Style = "linewidth 1 pointtype 6 pointsize 1";
  GS.ImposeDistr(gsdInDeg, FNmPref, Desc1, false, false, gpwLinesPoints, Style);
  GS.ImposeDistr(gsdInDeg, FNmPref+"-B", Desc1, true, false, gpwLinesPoints, Style);
  GS.ImposeDistr(gsdOutDeg, FNmPref, Desc1, false, false, gpwLinesPoints, Style);
  GS.ImposeDistr(gsdOutDeg, FNmPref+"-B", Desc1, true, false, gpwLinesPoints, Style);
  GS.ImposeDistr(gsdHops, FNmPref, Desc1, false, false, gpwLinesPoints, Style);
  GS.ImposeDistr(gsdClustCf, FNmPref, Desc1, false, false, gpwLinesPoints, Style);
  GS.ImposeDistr(gsdClustCf, FNmPref+"-B", Desc1, true, false, gpwLinesPoints, Style);
  GS.ImposeDistr(gsdSngVal, FNmPref, Desc1, false, false, gpwLinesPoints, Style);
  GS.ImposeDistr(gsdSngVal, FNmPref+"-B", Desc1, true, false, gpwLinesPoints, Style);
  GS.ImposeDistr(gsdSngVec, FNmPref, Desc1, false, false, gpwLinesPoints, Style);
  GS.ImposeDistr(gsdSngVec, FNmPref+"-B", Desc1, true, false, gpwLinesPoints, Style);
  GS.ImposeDistr(gsdWcc, FNmPref, Desc1, false, false, gpwLinesPoints, Style);
  GS.ImposeDistr(gsdWcc, FNmPref+"-B", Desc1, true, false, gpwLinesPoints, Style);
  GS.ImposeDistr(gsdScc, FNmPref, Desc1, false, false, gpwLinesPoints, Style);
  GS.ImposeDistr(gsdScc, FNmPref+"-B", Desc1, true, false, gpwLinesPoints, Style);
//    typedef enum { distrUndef, distrInDeg, distrOutDeg, distrWcc, distrScc,
//  distrHops, distrWccHops, distrSngVal, distrSngVec, distrClustCf, distrMx } TGraphDistr;*/
}

Here is the call graph for this function:

void TKronMtx::PlotCmpGraphs	(	const TKronMtx &	SeedMtx1,
		const TKronMtx &	SeedMtx2,
		const PNGraph &	Graph,
		const TStr &	OutFNm,
		const TStr &	Desc
	)		`[static]`

!!

Definition at line 514 of file kronecker.cpp.

References TStr::CStr(), TSnap::DelZeroDegNodes(), TStr::Fmt(), GenFastKronecker(), GenKronecker(), TNGraph::GetEdges(), GetKronIter(), GetMtxStr(), TNGraph::GetNodes(), gpwLinesPoints, gsdClustCf, gsdHops, gsdInDeg, gsdOutDeg, gsdScc, gsdSngVal, gsdSngVec, gsdTriadPart, gsdWcc, and tmuNodes.

                                                                                                                                            {
  const int KronIters1 = SeedMtx1.GetKronIter(Graph->GetNodes());
  const int KronIters2 = SeedMtx2.GetKronIter(Graph->GetNodes());
  PNGraph KronG1, KronG2;
  const bool FastGen = true;
  if (FastGen) {
    KronG1 = TKronMtx::GenFastKronecker(SeedMtx1, KronIters1, true, 0);
    KronG2 = TKronMtx::GenFastKronecker(SeedMtx2, KronIters2, false, 0); }
  else {
    KronG1 = TKronMtx::GenKronecker(SeedMtx1, KronIters1, true, 0);
    KronG2 = TKronMtx::GenKronecker(SeedMtx2, KronIters2, true, 0);  }
  TSnap::DelZeroDegNodes(KronG1);
  TSnap::DelZeroDegNodes(KronG2);
  const TStr Desc1 = TStr::Fmt("%s", Desc.CStr());
  TGStatVec GS(tmuNodes, TFSet() | gsdInDeg | gsdOutDeg | gsdWcc | gsdScc | gsdHops | gsdClustCf | gsdSngVec | gsdSngVal | gsdTriadPart);
  //gsdHops
  //gsWccHops, gsdSngVal, gsdSngVec, gsdClustCf
  GS.Add(Graph, TSecTm(1), TStr::Fmt("GRAPH  G(%d, %d)", Graph->GetNodes(), Graph->GetEdges()));
  GS.Add(KronG1, TSecTm(2), TStr::Fmt("KRONECKER1  K(%d, %d) %s", KronG1->GetNodes(), KronG1->GetEdges(), SeedMtx1.GetMtxStr().CStr()));
  GS.Add(KronG2, TSecTm(3),  TStr::Fmt("KRONECKER2  K(%d, %d) %s", KronG2->GetNodes(), KronG2->GetEdges(), SeedMtx2.GetMtxStr().CStr()));
  const TStr Style = "linewidth 1 pointtype 6 pointsize 1";
  // raw data
  GS.ImposeDistr(gsdInDeg, FNmPref, Desc1, false, false, gpwLinesPoints, Style);
  GS.ImposeDistr(gsdOutDeg, FNmPref, Desc1, false, false, gpwLinesPoints, Style);
  GS.ImposeDistr(gsdHops, FNmPref, Desc1, false, false, gpwLinesPoints, Style);
  GS.ImposeDistr(gsdClustCf, FNmPref, Desc1, false, false, gpwLinesPoints, Style);
  GS.ImposeDistr(gsdSngVal, FNmPref, Desc1, false, false, gpwLinesPoints, Style);
  GS.ImposeDistr(gsdSngVec, FNmPref, Desc1, false, false, gpwLinesPoints, Style);
  GS.ImposeDistr(gsdWcc, FNmPref, Desc1, false, false, gpwLinesPoints, Style);
  GS.ImposeDistr(gsdScc, FNmPref, Desc1, false, false, gpwLinesPoints, Style);
  GS.ImposeDistr(gsdTriadPart, FNmPref, Desc1, false, false, gpwLinesPoints, Style);
  // smooth
  GS.ImposeDistr(gsdInDeg, FNmPref+"-B", Desc1, true, false, gpwLinesPoints, Style);
  GS.ImposeDistr(gsdOutDeg, FNmPref+"-B", Desc1, true, false, gpwLinesPoints, Style);
  GS.ImposeDistr(gsdClustCf, FNmPref+"-B", Desc1, true, false, gpwLinesPoints, Style);
  GS.ImposeDistr(gsdScc, FNmPref+"-B", Desc1, true, false, gpwLinesPoints, Style);
  GS.ImposeDistr(gsdWcc, FNmPref+"-B", Desc1, true, false, gpwLinesPoints, Style);
  GS.ImposeDistr(gsdSngVec, FNmPref+"-B", Desc1, true, false, gpwLinesPoints, Style);
  GS.ImposeDistr(gsdSngVal, FNmPref+"-B", Desc1, true, false, gpwLinesPoints, Style);
  GS.ImposeDistr(gsdTriadPart, FNmPref+"-B", Desc1, true, false, gpwLinesPoints, Style);
}

Here is the call graph for this function:

void TKronMtx::PlotCmpGraphs	(	const TVec< TKronMtx > &	SeedMtxV,
		const PNGraph &	Graph,
		const TStr &	FNmPref,
		const TStr &	Desc
	)		`[static]`

Definition at line 556 of file kronecker.cpp.

References TStr::CStr(), TSnap::DelZeroDegNodes(), TStr::Fmt(), GenFastKronecker(), TNGraph::GetEdges(), TNGraph::GetNodes(), gpwLines, gsdClustCf, gsdHops, gsdInDeg, gsdOutDeg, gsdScc, gsdSngVal, gsdSngVec, gsdWcc, TVec< TVal >::Len(), and tmuNodes.

                                                                                                                        {
  const TStr Desc1 = TStr::Fmt("%s", Desc.CStr());
  TGStatVec GS(tmuNodes, TFSet() | gsdInDeg | gsdOutDeg | gsdWcc | gsdScc | gsdHops | gsdClustCf | gsdSngVec | gsdSngVal);
  GS.Add(Graph, TSecTm(1), TStr::Fmt("GRAPH  G(%d, %d)", Graph->GetNodes(), Graph->GetEdges()));
  //gsdHops
  //gsWccHops, gsdSngVal, gsdSngVec, gsdClustCf
  for (int m = 0; m < SeedMtxV.Len(); m++) {
    const int KronIters = SeedMtxV[m].GetKronIter(Graph->GetNodes());
    PNGraph KronG1 = TKronMtx::GenFastKronecker(SeedMtxV[m], KronIters, true, 0);
    printf("*** K(%d, %d) n0=%d\n", KronG1->GetNodes(), KronG1->GetEdges(), SeedMtxV[m].GetDim());
    TSnap::DelZeroDegNodes(KronG1);
    printf(" del zero deg K(%d, %d) n0=%d\n", KronG1->GetNodes(), KronG1->GetEdges(), m);
    GS.Add(KronG1, TSecTm(m+2), TStr::Fmt("K(%d, %d) n0^k=%d n0=%d", KronG1->GetNodes(), KronG1->GetEdges(), SeedMtxV[m].GetNZeroK(Graph), SeedMtxV[m].GetDim()));
    // plot after each Kronecker is done
    const TStr Style = "linewidth 1 pointtype 6 pointsize 1";
    GS.ImposeDistr(gsdInDeg, FNmPref, Desc1, false, false, gpwLines, Style);
    GS.ImposeDistr(gsdInDeg, FNmPref+"-B", Desc1, true, false, gpwLines, Style);
    GS.ImposeDistr(gsdOutDeg, FNmPref, Desc1, false, false, gpwLines, Style);
    GS.ImposeDistr(gsdOutDeg, FNmPref+"-B", Desc1, true, false, gpwLines, Style);
    GS.ImposeDistr(gsdHops, FNmPref, Desc1, false, false, gpwLines, Style);
    GS.ImposeDistr(gsdClustCf, FNmPref, Desc1, false, false, gpwLines, Style);
    GS.ImposeDistr(gsdClustCf, FNmPref+"-B", Desc1, true, false, gpwLines, Style);
    GS.ImposeDistr(gsdSngVal, FNmPref, Desc1, false, false, gpwLines, Style);
    GS.ImposeDistr(gsdSngVal, FNmPref+"-B", Desc1, true, false, gpwLines, Style);
    GS.ImposeDistr(gsdSngVec, FNmPref, Desc1, false, false, gpwLines, Style);
    GS.ImposeDistr(gsdSngVec, FNmPref+"-B", Desc1, true, false, gpwLines, Style);
    GS.ImposeDistr(gsdWcc, FNmPref, Desc1, false, false, gpwLines, Style);
    GS.ImposeDistr(gsdWcc, FNmPref+"-B", Desc1, true, false, gpwLines, Style);
    GS.ImposeDistr(gsdScc, FNmPref, Desc1, false, false, gpwLines, Style);
    GS.ImposeDistr(gsdScc, FNmPref+"-B", Desc1, true, false, gpwLines, Style);
  }
  //    typedef enum { distrUndef, distrInDeg, distrOutDeg, distrWcc, distrScc,
  //  distrHops, distrWccHops, distrSngVal, distrSngVec, distrClustCf, distrMx } TGraphDistr;*/
}

Here is the call graph for this function:

void TKronMtx::PutAllMtx ( const double & Val ) [inline]

Definition at line 39 of file kronecker.h.

References TVec< TVal >::PutAll(), and SeedMtx.

{ SeedMtx.PutAll(Val); }

Here is the call graph for this function:

static void TKronMtx::PutRndSeed ( const int & Seed ) [inline, static]

Definition at line 108 of file kronecker.h.

References TRnd::PutSeed(), and Rnd.

Referenced by TKronMaxLL::Test().

{ TKronMtx::Rnd.PutSeed(Seed); }

Here is the call graph for this function:

Here is the caller graph for this function:

void TKronMtx::SaveTxt ( const TStr & OutFNm ) const

Definition at line 14 of file kronecker.cpp.

References At(), TStr::CStr(), F(), and GetDim().

                                               {
  FILE *F = fopen(OutFNm.CStr(), "wt");
  for (int i = 0; i < GetDim(); i++) {
    for (int j = 0; j < GetDim(); j++) {
      if (j > 0) fprintf(F, "\t");
      fprintf(F, "%f", At(i,j)); }
    fprintf(F, "\n");
  }
  fclose(F);
}

Here is the call graph for this function:

void TKronMtx::SetEpsMtx	(	const double &	Eps1,
		const double &	Eps0,
		const int &	Eps1Val = `1`,
		const int &	Eps0Val = `0`
	)

Definition at line 50 of file kronecker.cpp.

References At(), and Len().

                                                                                                       {
  for (int i = 0; i < Len(); i++) {
    double& Val = At(i);
    if (Val == Eps1Val) Val = double(Eps1);
    else if (Val == Eps0Val) Val = double(Eps0);
  }
}

Here is the call graph for this function:

void TKronMtx::SetForEdges	(	const int &	Nodes,
		const int &	Edges
	)

Definition at line 59 of file kronecker.cpp.

References At(), GetKronIter(), GetMtxSum(), and Len().

Referenced by GetInitMtx().

                                                             {
  const int KronIter = GetKronIter(Nodes);
  const double EZero = pow((double) Edges, 1.0/double(KronIter));
  const double Factor = EZero / GetMtxSum();
  for (int i = 0; i < Len(); i++) {
    At(i) *= Factor;
    if (At(i) > 1) { At(i) = 1; }
  }
}

Here is the call graph for this function:

Here is the caller graph for this function:

void TKronMtx::SetMtx ( const TFltV & ParamV ) [inline]

Definition at line 37 of file kronecker.h.

References SeedMtx.

{ SeedMtx = ParamV; }

void TKronMtx::SetRndMtx	(	const int &	MtxDim,
		const double &	MinProb = `0.0`
	)

Definition at line 40 of file kronecker.cpp.

References TVec< TVal >::Gen(), TRnd::GetUniDev(), TVec< TVal >::Len(), MtxDim, and SeedMtx.

Referenced by GetRndMtx().

                                                                    {
  MtxDim = PrmMtxDim;
  SeedMtx.Gen(MtxDim*MtxDim);
  for (int p = 0; p < SeedMtx.Len(); p++) {
    do {
      SeedMtx[p] = TKronMtx::Rnd.GetUniDev();
    } while (SeedMtx[p] < MinProb);
  }
}

Here is the call graph for this function:

Here is the caller graph for this function:

void TKronMtx::Swap ( TKronMtx & KronMtx )

Definition at line 114 of file kronecker.cpp.

References MtxDim, SeedMtx, and TVec< TVal >::Swap().

Referenced by KronPwr().

                                     {
  ::Swap(MtxDim, KronMtx.MtxDim);
  SeedMtx.Swap(KronMtx.SeedMtx);
}

Here is the call graph for this function:

Here is the caller graph for this function:

void TKronMtx::ToOneMinusMtx ( )

Definition at line 91 of file kronecker.cpp.

References At(), IAssert, and Len().

                             {
  for (int i = 0; i < Len(); i++) {
    IAssert(At(i) >= 0.0 && At(i) <= 1.0);
    At(i) = 1.0 - At(i);
  }
}

Here is the call graph for this function:

Member Data Documentation

TInt TKronMtx::MtxDim [private]

Definition at line 16 of file kronecker.h.

Referenced by At(), GenFastKronecker(), GenMtx(), GetApxNoEdgeDLL(), GetDim(), GetEdgeDLL(), GetEdgeLL(), GetEdgeProb(), GetLLMtx(), GetNoEdgeDLL(), GetProbMtx(), IsEdgePlace(), operator=(), SetRndMtx(), Swap(), and TKronMtx().

const double TKronMtx::NInf = -DBL_MAX [static]

Definition at line 13 of file kronecker.h.

Referenced by GetApxNoEdgeDLL(), GetEdgeLL(), GetLLMtx(), GetProbMtx(), TKroneckerLL::InitLL(), and KronSum().

TRnd TKronMtx::Rnd = TRnd(0) [static]

Definition at line 14 of file kronecker.h.

Referenced by AddRndNoise(), GenDetKronecker(), GenFastKronecker(), GenKronecker(), and PutRndSeed().

TFltV TKronMtx::SeedMtx [private]

Definition at line 17 of file kronecker.h.

Referenced by At(), Dump(), Empty(), GenDetKronecker(), GenFastKronecker(), GenKronecker(), GenMtx(), GetMtx(), GetPrimHashCd(), GetSecHashCd(), Len(), operator=(), operator==(), PutAllMtx(), SetMtx(), SetRndMtx(), Swap(), and TKronMtx().

The documentation for this class was generated from the following files:

snap-adv/kronecker.h
snap-adv/kronecker.cpp

Public Member Functions

Static Public Member Functions

Static Public Attributes

Private Attributes

Detailed Description

Constructor & Destructor Documentation

Member Function Documentation

Member Data Documentation
